Multi

Basic Info.

Model NO.	YHY-913
Sample	Available
Service	Width and Length Can Be Welded
Popular Market	Us,Australia,Garmany
Delivery Time	20days
Feature	Nice Surface ,Stable
Roll Length	Max 50 Meter
Panel Width	Max 1.5 Meter
Panel Length	0.5 Meter to 3meter
Plate Thinkess	0.3mm to 15mm
Other Hole Shape	Round,Diamond,Square,Hexagonal,Fish Scale
Transport Package	Pallet, Water-Proof Paper, Wooden Case
Specification	Width: 0.1 to 2 meter
Trademark	YHY
Origin	Hebei, China
HS Code	7314500000
Production Capacity	10000m2 Per Day

Product Description

YHY offers perforated metal in different patterns materials and thickness.Material :Stainless Steel ,Plain Steel ,Galvanized Steel,Aluminum, Brass (Copper) ,Phosphor or BronzeFeatures: also named Punched Mesh, It can be supplied in folded or flat panels. From various metal plates, punched openings can be round, square, triangle, diamond, hexagonal, cross, etc.

ROUND HOLES STAGGERED PATTERN
HOLE	CENTERS	GAUGE / PLATE THICK.	OPEN AREA
.020" RD	.045" Stag	26	18%
1/32" RD	1/16" Stag	22	23%
3/64" RD	5/64" Stag	24	33%
3/64" RD	3/32" Stag	22 thru 18	23%
1/16" RD	3/32"Stag	22 thru 16	40%
1/16" RD	7/64" Stag	20 thru 16	30%
1/16" RD	1/8" Stag	26 thru 16	23%
5/64" RD	1/8" Stag	22 thru 14	35%
3/32" RD	5/32" Stag	24 thru 14	33%
3/32" RD	3/16" Stag	24	23%
.117 RD	5/32" Stag	18	51%
1/8" RD	3/16" Stag	24 thru 11	40%
1/8" RD	7/32" Stag	14 thru 12	30%
1/8" RD	1/4" Stag	14, 13	23%
9/64" RD	3/16" Stag	18	51%
5/32" RD	3/16" Stag	22 thru 16	63%
5/32" RD	1/4" Stag	20 thru 10	35%
3/16" RD	7/32" Stag	22 thru 16	67%
3/16" RD	1/4" Stag	24 thru 12	51%
3/16" RD	5/16" Stag	10, 3/16"	33%
3/16" RD	3/8" Stag	14 thru 10	23%
1/4" RD	5/16" Stag	20 thru 16	58%
1/4" RD	3/8" Stag	26 thru 1/4"	40%
17/64" RD	5/16" Stag	20	66%
5/16"RD	7/16" Stag	20 thru 1/4"	46%
3/8" RD	9/16" Stag	20 thru 1/4"	40%
1/2" RD	11/16" Stag	20 thru 1/4"	48%
1/2" RD	3/4" Stag	16	40%
5/8" RD	7/8" Stag	10 thru 1/4"	46%
3/4" RD	1" Stag	16 thru 1/4"	51%
1" RD	1-3/8" Stag	10 thru 1/4"	48%
1-1/4" RD	1-5/8" Stag	1/4"	54%
1-1/2" RD	2" Stag	1/4"	51%
2" RD	2-1/2" Stag	1/4"	58%
2-1/2" RD	3" Stag	3/16"	63%
3" RD	3-1/2" Stag	3/16"	67%
4" RD	4-1/2" Stag	10	72%

Applications: The opening size, density and forms of distribution can bring different functions in separation, sifting, filtration, drying, cooling, cleaning, etc
YHY products have been exported to 50 courtiers and area. Now our sales department has a completely sales system, we offer customers price within 8 hours, and make samples within 5 days.
YHY People always making efforts to improve our technical and develop new products. Our target is to be the top one of metal wire mesh industry in China within 5 five years and make our customer's satisfactions be 100%.

1. Are you a manufacturer?
Yes, we are the ISO and CE certificated Manufacturer and our factory founded in this industry since 1989.

2. Will your price competitive?
Yes , we have stable and large raw material supplier ,we work with them for nearly 20 years . Our machine and technical it is most advanced , we will send our technical to aboard to learning new technical every year.

3.Can we have a sample ?
Yes , if the samples it is not much big , we can offer free sample , the courier it is paid by customers.

4.Can we visit your factory ?
Yes , you are welcome to visit us . we can pick you up from the airport .

5. What are the payment terms?
We can accept TT , LC , West Union , Money Gram , Cash .
